Quick Details

  • Type: Laboratory Furniture
  • General Use: Commercial Furniture
  • Material: Metal
  • Metal Type: galvanized steel plain sheet
  • Size: 1200/1500/1800W*800D*2350H(mm)
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SFS
  • Model Number: BH01-006
  • Product name: Laboratory fume cupboards, fume hood, bench mounted fume cupboard
  • Place of origin: Guangzhou, China (Mainland)
  • Factory: Yes
  • Size of working area: 950/1250/1550W*700D*1150H(mm))
  • Packing: Knocked-down Packaging
  • CBM: 0.82, 0.9, 1.05
  • NW: 150, 170, 210kgs
  • GW: 180, 200, 250 kgs
  • Color: Off-white, blue or customized
  • Material of worktop: solid physiochemical board or epoxy resin table - board

Packaging & Delivery

Packaging Details: For Container order the Normal Carton Packing and for the LCL Shipment Wooden Case packing to ensure the safety of goods, knock down packing, kraft Board Bound with iron Belts Externally, Each unit with assemble instruction in the packing carton.
Delivery Detail: 5 days after deposit payment done.
Detailed Images

All pictures for real photos in our factory !













 The best for equipment and variability .

Along with the convenient basic equipment, our fume cupboards provide a wide range of variable equipment options .

Depending on the application, the worktop is made of technical ceramic material, solid physiochemical board or epoxy resin table - board, stainless steel , and is quick and easy to replace . Our fume cupboards have a self- supporting structure. You can install under the fume cupboard, plinth mounted, mobile or metal solvent cabinets .

The integrated service panels installed in the rear panel are quick to replace , in addition the sink  module integrated into the rear panel provides more freedom in the use of the work surface.

All control elements for our fume cupboards are designed for ease of use aloong with the maximum possible safety of the user.



Product percific:

Standard size: 1200*800*2350mm, 1500*800*2350mm, 1800*800*2350mm

Table: 12.7 mm thickness  chemical-Resistant Laminate which is resistant of
 acidand alkali , Chemsurf core physical and chemical board table imported by theUnited States,strong acid resistant and alkali resistant, wear-resistant. High temperatures, along the edge of the stick handling,  a waterproof edge; the surface color: black;
Cabinet:
On top tank, it adopts 1.2mm thick high quality cold-rolled steel plate bending jointing molding.Epoxy resin powder electrostatic high pressure sprays the surface. Acid and alkali resistant.It adopts 40mm*40mm*1.8mm steel for framework to joint into integrated at bottom framework; epoxy resin powder electrostatic sprays treatment on the surface after embalmment;
All steel structure lower tanks, it adopts 1.5mm thick high quality cold rolled steel with welding treatment. Epoxy powder electrostatic high-pressure spray treatment on the surface. It is acid and alkali resistant;
Windows: adopting 5mm tempered glass, infinite variable speed counterpoise weight in the design, comfortable window movements to locate at any position;
Power distribution: use high quality socket, standard is triplex sockets rated current at 16A, 10A five-hole sockets,2 5A/380V quadruplet sockets;
Exhaust: three stages exhaust in the designing, no exhaust corner, adjustable flow rate, wind speed reaches 0.5m/s~0.8m/s;
Lighting :30 (40W) hidden fluorescent light;
Function: the body is equipped with the protection devices for leakage, overload, short circuit and the controlling system is equipped for blower;
Sink: 6mm thickness imported PP materials to make an integrity, pressure-proof, corrosion resistance and stand fire;
Water faucet: imported Fume hood set special simplex water faucet, it is anticorrosion;
Hinges: 90 degrees,180 degrees adjustable, high quality hinge made in Guangzhou;
Tail :stainless steel with rubber can adjust tail, height to 50mm,the height of sliding door is 800mm~1000mm;
Noise: inner cabinet ≤65db, outer cabinet ≤55db;

Packaging & Shipping

Packaging Details:

EPE foam+plastic bubble film +hard carton for FCL order.
EPE foam+plastic bubble film+hard carton + wooden case for LCL order.

Delivery Detail:

Shipped in about 10 days after payment done

Our Services



Company Information

GuangZhou Scienfocus Lab Equipment Co.,Ltd is a manufacturer of laboratory furniture with well-equipped testing facilities and strong technical force.

Our factory located in Huadu Area Guangzhou City where is the Guangzhou Baiyun New airport located too .We have 3 years export experiment of lab furniture and 15 years lab engineering system construction accumulation.



Shipment:



FAQ

Why choose us ?

1.OEM and ODM service.Directly manufacturing factory with competitive price and quality control,we check all material when we start to bulk product  productions

2.Professional advice to help you purchase the products you wanted

3.Professional export service team servers in the deal

4.Customization service is available ,OEM business is appreciated

5.We will inspect and test all products material carefully to ensure no damage and lost

6.The success of our cooperation can be guaranteed for our company is a credible and honest partner.



How to place an order ?

1.Contact by e-mail or trade manager for specified items

2.Contract signed , 40% deposit in advance

3.Bulk productions

4.Balance payment before shipment .

5.Shipping send original documents or tele-release goods

6.Quality warranty for 2 years after shipment .



Do you have products in stocks?

Some itemS we reserve stocks .If there is no any stocks, we will inform you with details in the reply of your require.



How much will the shipping charges be ?

This is depends on the size of your shipment and the method of shipping .When inquire about the shipping charges , we hope that you let us know the detailed information such as the codes and the quantity .Your favorable method of shipping .( by sea or by air ) and your designated port or air port .We will be gradeful if you can spare us some minutes to help us since it will enable us to evaluate the cost based on the information provided .



Can I visit your factory ?

Sure ,We are a manufacturer of lab furniture in Guangzhou ,China .Please contact us in advance and will make an appointment with you.CE certificated lab furniture with gas valve
